What is the purpose of a gas control panel in a Medical Gas Pipeline System (MGPS) connection?

A gas control panel in an Medical Gas Pipeline System(MGPS) regulates pressure, controls gas flow, and ensures uninterrupted supply with safety alarms and switchover functions.

How does the Gas control panel in the Medical Gas Pipeline System (MGPS) help eliminate risks?

A Gas Control Panel in an MGPS eliminates risks by regulating pressure, ensuring stable gas flow, and activating alarms for pressure drops or faults, preventing supply failures.

Our Products

SEMI AUTOMATIC GAS CONTROL PANEL

Our Semi-automatic gas control panels with manifolds are designed to accurately monitor and regulate gas levels. Known for their precision and reliability, these advanced control systems ensure optimal performance in critical applications.

Specification:

Our semi-automatic gas control panel features a logic-controlled auto change-over system that ensures a constant, uninterrupted gas supply. It provides stable discharge pressure and flow, with visual and audible signals for monitoring. The panel offers flexible pressure unit display options, including bar, psi, and kg/cm², and optimizes the residual gas in cylinders for efficient usage.

Application:

Our semi-automatic gas control panel is designed for precise management of CO2 flow at 4.2 bar, featuring contact pressure gauges for accurate monitoring and customizable audio alarms. It includes gas bank status indicators and maintains stable discharge pressure, making it ideal for various medical gasses. The system’s pneumatic switch-over, triggered by a differential between primary regulators, requires manual resetting, ensuring reliable and gas-specific performance in medical applications.

FULLY AUTOMATIC GAS CONTROL PANEL ( 2 SOURCE )

Our fully automatic gas control panel with switchover gas manifolds ensures a continuous gas supply by automatically switching between two equal banks of cylinders. Designed for convenience, it regulates cylinder pressure to deliver uninterrupted gas, providing a cost-effective solution that eliminates the need for trailing hoses in operating rooms.

Specifications:

Our fully automatic control panel, compliant with NFPA 99, features a lockable metal cover for enhanced safety and durability, automatic saddle valve switching between gas sources, and a pressure-reducing design for stable output. It includes a clear pressure gauge/LED display, microprocessor-based PLC for maintenance, and color-coded hoses for safety. Audio and visual alarms activate upon gas source depletion, and it is suitable for O2, air, N2O, and CO2 applications.

Application:

Our fully automatic control panel, designed to NFPA 99 standards, is ideal for ensuring a continuous and safe gas supply in critical environments. It automatically switches between two gas sources with precise pressure regulation and provides clear pressure readings via LED display. With features like microprocessor-based PLC for maintenance, color-coded hoses for enhanced safety, and alarms for gas depletion, it is suited for managing O2, air, N2O, and CO2 in medical and industrial applications.
